Lightweight & Flexible
Made of high-performance FRC material, the screen is ultra-light, ultra-thin, and features outstanding flexibility.
Flexible LED Screen
Flexible LED screens are ultra-light, ultra-thin, and highly bendable, designed to turn any curved or irregular surface into a vivid display.
They deliver seamless visuals with high refresh rates and 16-bit grayscale, bringing creative, eye-catching solutions to commercial spaces, brand stores, and immersive experiences.
They deliver seamless visuals with high refresh rates and 16-bit grayscale, bringing creative, eye-catching solutions to commercial spaces, brand stores, and immersive experiences.
2026 New Flexible LED Screen Solutions for You
After submission, our advisor will respond with a quote within 1 business hour. Your information is strictly confidential, and we promise no leakage or spam.
Key Advantages of Flexible LED Screen
Lightweight, high-transparency and durable design, ideal for architectural lighting and commercial displays
Outstanding Display Performance
Delivers vivid visuals with 16-bit grayscale processing and high refresh rate, ensuring smooth and clear images.
360° Viewing Angle
Supports seamless splicing and fully adapts to streamlined designs, delivering consistent visuals from all directions.
User-Friendly Installation
Strong magnetic adsorption design allows for quick installation and convenient maintenance.
Freely Customizable
Supports diversified shape customization to meet the creative requirements of various projects.
High Flexibility
Can be freely bent, folded, and combined into various artistic shapes for maximum creative freedom.
Common Shapes of Flexible LED Screens
Flexible LED screens break the shape limitations of traditional displays with excellent plasticity, adapting to various special structures to meet creative display needs. Below are the most common shapes:
Cylindrical LED Display
These 360° wraparound screens transform building columns into digital art installations. They are ideal for shopping mall atriums to create immersive navigation systems, or museums to present holographic exhibits. No matter the viewing angle, they deliver seamless, dynamic visuals.
Spherical LED Display
Spherical screens, assembled from flexible modules, break the dimensional limits of flat displays. They are widely used in science museums to show real-time weather data, bars as music-reactive light installations, and urban landmarks to add technological appeal to night scenes.
Curved LED Display
Leveraging the bending properties of flexible modules, curved LED screens create smooth, natural visual effects. Compared to flat displays, they offer a wider viewing angle with reduced distortion, making them perfect for stage backgrounds, gymnasiums, and conference centers.
Ribbon LED Display
Designed for creative decoration, ribbon LED screens can bend like a ribbon to form unique visuals. They adapt to complex installation environments, supporting hanging, bending, and wrapping setups. Common uses include building facades, mall atriums, and stage art installations.
Canned LED Display
Shaped like a beverage can, these screens feature a distinctive form with 360° high-definition display. They are ideal for shopping malls, exhibitions, and bars, especially for beverage brand marketing and promotional campaigns.
Where Flexible LED Screen Shines
Elevate spaces with transparent, lightweight, and flexible visual experiences
Commercial Estate
Ideal for shopping malls, glass curtain walls, sightseeing elevator facades, and high-end commercial buildings. It transforms traditional static facades into eye-catching digital media, enhancing the brand image and commercial value of the property.
Brand Chain Stores
Perfect for 3C experience stores, bank business halls, restaurants, bakeries, clothing and jewelry stores. It delivers vivid brand content to attract customers, boost foot traffic, and strengthen the brand’s visual identity.
Traffic Advertising Media
Designed for high-traffic public spaces such as airport terminals, high-speed rail stations, subway stations, and bus stations. It delivers clear and impactful advertising and information to a large, fast-moving audience.
Creative Display
Tailored for immersive experiences in bars, stage events, landscape cultural tourism projects, and TV shows. Its flexible design enables unique artistic installations and creative visual effects that bring any creative concept to life.
2026 New Flexible LED Screen Solutions for You
After submission, our advisor will respond with a quote within 1 business hour. Your information is strictly confidential, and we promise no leakage or spam.
Real-World Projects
See how our Flexible LED Screen transform spaces worldwide
Products
Flexible Module Technical Specifications
Key Parameters of Our LED Mesh Screen
| Item | ZR-BF-P1.88 | ZR-BF-P2 | ZR-BF-P2.5 | ZR-BF-P3 | ZR-BF-P4 |
|---|---|---|---|---|---|
| Pixel Pitch | 1.88mm | 2mm | 2.5mm | 3mm | 4mm |
| Pixel Density | 282933 dots/m² | 250000 dots/m² | 160000 dots/m² | 111111 dots/m² | 62500 dots/m² |
| Module Power | 25W | 24W | 20W | 16W | 20W |
| Module Size | 320×160mm | 320×160mm | 320×160mm | 320×160mm | 320×160mm |
| Module Resolution | 170×85 dots | 160×80 dots | 128×64 dots | 104×52 dots | 80×40 dots |
| Scan Mode | 1/43 | 1/40 | 1/32 | 1/26 | 1/20 |
| Module Weight | 0.32kg | 0.30kg | 0.28kg | 0.26kg | 0.24kg |
| LED Configuration | SMD1515 | SMD1515 | SMD1515 | SMD1515 | SMD2020 |
| Brightness | 700–900 nits | 700–900 nits | 700–900 nits | 700–900 nits | 700–900 nits |
| Refresh Rate | 3840Hz | 3840Hz | 1920Hz / 3840Hz | 1920Hz / 3840Hz | 1920Hz / 3840Hz |
| Operating Voltage | 4.2–5V | 4.2–5V | 4.2–5V | 4.2–5V | 4.2–5V |
| Rated Current | 5A | 4.8A | 3.8A | 3.2A | 4A |
| Thickness | 8.6mm | 8.6mm | 8.6mm | 8.6mm | 8.6mm |
| Model | ZR-SF-P1.25 | ZR-SF-P1.579 | ZR-SF-P1.667 | ZR-SF-P1.875 | ZR-SF-P2 | ZR-SF-P2.5 | ZR-SF-P3 |
|---|---|---|---|---|---|---|---|
| Pixel Pitch | 1.25mm | 1.579mm | 1.667mm | 1.875mm | 2mm | 2.5mm | 3mm |
| Pixel Density | 640000 dots/m² | 400689 dots/m² | 358801 dots/m² | 284444 dots/m² | 250000 dots/m² | 160000 dots/m² | 111111 dots/m² |
| Module Power | 19W | 17.5W | 16W | 19W | 18W | 14W | 12.5W |
| Module Size | 240×120mm | 240×120mm | 240×120mm | 240×120mm | 240×120mm | 240×120mm | 240×120mm |
| Module Resolution | 192×96 dots | 152×76 dots | 144×72 dots | 128×64 dots | 120×60 dots | 96×48 dots | 80×40 dots |
| Scan Mode | 1/48 | 1/38 | 1/36 | 1/32 | 1/30 | 1/24 | 1/20 |
| Module Weight | 0.25kg | 0.23kg | 0.22kg | 0.20kg | 0.19kg | 0.185kg | 0.175kg |
| LED Configuration | SMD1010 | SMD1212 | SMD1212 | SMD1515 | SMD1515 | SMD1515 | SMD1515 |
| Brightness | 700–900 nits | 700–900 nits | 700–900 nits | 700–900 nits | 700–900 nits | 700–900 nits | 700–900 nits |
| Refresh Rate | 3840Hz | 3840Hz | 3840Hz | 3840Hz | 3840Hz | 1920Hz / 3840Hz | 1920Hz / 3840Hz |
| Operating Voltage | 4.2–5V | 4.2–5V | 4.2–5V | 4.2–5V | 4.2–5V | 4.2–5V | 4.2–5V |
| Rated Current | 3.8A | 3.2A | 3A | 3.8A | 3.6A | 2.8A | 2.5A |
| Thickness | 8.6mm | 8.6mm | 8.6mm | 8.6mm | 8.6mm | 8.6mm | 8.6mm |
Why Luminatii
Built on In-House Manufacturing & National High-Tech Expertise
Large-Scale Project Experience
Official LED display supplier for the 19th Asian Games Opening Ceremony, proven for 5000㎡+ large-scale projects.
Global Validation with Export to 87 Countries
Products exported to 87 countries & regions, backed by a global sales and service network.
Comprehensive Product Line with High Specifications
Full portfolio including transparent/mesh/flexible screens, IP65/IP67 rated with brightness up to 5000 cd/m².
Display Solutions Born for Creativity
Fully customizable panels for irregular shapes, with transparent screens that preserve building aesthetics.
Frequently Asked Questions
A flexible LED screen is a lightweight, bendable display made of flexible circuit boards and LED modules. Unlike traditional rigid LED screens, it can be freely curved, folded, and shaped into various forms to adapt to non-planar installation environments.
It features ultra-light and ultra-thin design, high flexibility for custom shapes, seamless splicing for smooth visuals, magnetic installation for quick setup, and support for 16-bit grayscale and high refresh rates for vivid images.
They are widely used in creative installations, curved walls, ceiling decorations, cylindrical pillars, brand store displays, commercial real estate facades, and themed exhibitions, enabling unique visual experiences that rigid screens cannot achieve.
The screen uses strong magnetic adsorption installation, allowing for quick on-site assembly. Its modular design also enables front maintenance, making daily repairs and replacements simple and efficient without affecting the overall structure.
Standard flexible LED screens are mainly designed for indoor use. For outdoor applications, we can provide customized solutions with enhanced waterproof and dustproof grades to adapt to different environmental requirements.
Can’t find what you’re looking for?
Reach out to our team directly for personalized support on Flexible LED Screen.
